Bedmap2

Improved ice bed, surface and thickness datasets for Antarctica

Bedmap2 is a new suite of gridded products describing surface elevation, ice-thickness and the sea floor and subglacial bed elevation of the Antarctic south of 60◦ S. We derived these products using data from a variety of sources, including many substantial surveys completed since the original Bedmap compilation (Bedmap1) in 2001. In particular, the Bedmap2 ice thickness grid is made from 25 million measurements, over two orders of magnitude more than were used in Bedmap1. In most parts of Antarctica the subglacial landscape is visible in much greater detail than was previously available and the improved data coverage has in many areas revealed the full scale of mountain ranges, valleys, basins and troughs, only fragments of which were previously indicated in local surveys. The derived statistics for Bedmap2 show that the volume of ice contained in the Antarctic ice sheet (27 million km3) and its potential contribution to sea-level rise (58 m) are similar to those of Bedmap1, but the mean thickness of the ice sheet is 4.6 % greater, the mean depth of the bed beneath the grounded ice sheet is 72 m lower and the area of ice sheet grounded on bed below sea level is increased by 10 %. The Bedmap2 compilation highlights several areas beneath the ice sheet where the bed elevation is substantially lower than the deepest bed indicated by Bedmap1. These products, along with grids of data coverage and uncertainty, provide new opportunities for detailed modelling of the past and future evolution of the Antarctic ice sheets.

Access Publication and Data

The final manuscript is available through The Cryosphere.

Get Manuscript (6MB PDF)

Get Data

Bedmap2 Preview

Bedmap 2 - Preview - Small


More Information About Bedmap2

The Bedmap2 project, part of the International Polar Year (IPY), aims to assemble all new data on ice thickness and bed topography for Antarctica. The aim is to provide new ice surface and bed elevation maps for the continent and surrounding seas.

The original BEDMAP project, completed in 2000, brought together a strong international consortium of Antarctic scientists who pooled data from several decades of polar expeditions. It produced the first comprehensive maps of the Antarctic landscape that lay hidden under the ice sheets for hundreds of thousands of years. From these, the volume of Antarctic ice was revealed and, since then, many other research projects have used the maps to model ice sheet flow and for studies of geology, tectonics, crustal seismics, magnetics and ice core interpretation.
